Overview

APIC – Modular System Development Simplified

APIC is a modular, high-performance C++ development ecosystem designed to accelerate the design, integration, and validation of complex systems. It provides a unified workflow connecting simulation, configuration, monitoring, and user interface development — all within one cohesive framework.

Built for demanding environments such as defense, aerospace, and embedded applications, APIC enables engineers to move seamlessly from concept to production with minimal overhead and maximum reliability.

⚙️ Core Architecture

APIC applications are built around a C++ simulation and runtime core that manages data blocks defined in ICD (Interface Control Document) CSVs. These ICDs describe structured communication between system components and external Hardware, ensuring consistency from design through deployment.

CoreEngine — Real-time, cross-platform, high performance application that execute the integrated components and communicates with external devices.
DIPanel — Real-time data injection, monitoring, and recording tool. It communicates directly with the C++ application database and ICD-defined interfaces, providing live visualization of system activity.
Reflector — Waits for a remote CoreEngine to connect and reflects its shared memory locally, so local tools can monitor and interact with it as if it were running on your machine
DBSimGenerator — Generates simulation and interface code automatically from ICD (Interface Control Document) CSV files.
StatesHub — Real-time application states machine set and monitoring tool. It communicates directly with the C++ application model's states controllers, providing live visualization of system activity.
SystemConfig — Simplify configuration management, project organization, and build automation across heterogeneous targets.
SimReport — Real-time application to display simulation reports, general info, warnings, errors, and state machine messages
OGI — Operator Graphical Interface. A cross-platform UI framework for Windows, Linux, and embedded devices that connects seamlessly with both internal and external ICDs, enabling responsive and dynamic user interfaces.

🚀 Performance and Integration

APIC applications are optimized for real-time performance and low-latency communication. The generated C++ code is compact, scalable, and integrates with a wide range of hardware drivers, simulation streams, and external systems.

Direct ICD-to-code generation via DBSimGenerator
Tight integration between simulation data and visualization tools
Multi-target builds for Windows, Linux, NVIDIA Jetson, and embedded DSPs
Cross-application communication through shared memory, TCP, or driver interfaces

🧠 Why APIC?

APIC eliminates the need to reimplement common system layers — communication, configuration, monitoring, and visualization — allowing engineers to focus on core technology and innovation.

With its plug-and-play modular design, APIC supports rapid prototyping, scalable integration, and full-system validation — from unit testing to final acceptance.

From design to deployment — APIC streamlines every phase of complex system development.

APIC package applications

APIC package content

ICD Document

DBSimGenerator

Generate simulation code from ICD CSV documents quickly and reliably.

FRS Document

CoreEngine

Cross-platform applications developed from your simulation logic.

DIPanel

Inject, monitor, and record data for testing and analysis.

StateHub

Control and monitor system states with a centralized interface.

SystemConfig

Set up and generate system configurations effortlessly.

ORS Document

OGI

Cross-platform user interface for interaction and monitoring.

CoreEngine Reflector

Broadcasts and waits for a remote CoreEngine to connect, then reflects its shared memory locally — making the remote simulation appear as if it's running on your workstation. Local tools like DIPanel, SimReport, and OGI can then monitor and interact with it without direct access to the remote system.

Quick jump start

Need to get up and running fast? Follow the three simple steps below to generate simulation code from your ICD CSVs and explore advanced concepts when you're ready.

Prepare your ICD CSV — make sure headers match the required column names (ID, Type, Length, Description).
Upload to the DBSimGenerator — drop the CSV into the generator and verify the preview output.
Generate & test — download generated code, import into your project, and run a quick simulation.

Where to go next, depending on what you're doing:

🚀 Getting Start Guide Deeper explanations, examples, and troubleshooting tips. 🧭 For Software Engineers The system-engineering workflow, step by step. 💻 For Software Developers A fast-start, code-first tour for developers. 🎨 For Designers Build OGI screens with minimal need to coordinate with developers. ✅ For QA Engineers Build automated test flows with CSV tables - no C++ required.

Recommended Workflow

Define ICDs → DBSimGenerator
Define FRS → CoreEngine
Define ORS → OGI App
Develop → CoreEngine
Debug, Monitor & Inject data → DIPanel
Debug, App Flow Control → StateHub
Configure → SystemConfig
Define STD Á ATP → Automated Tests and Reports in CoreEngine
Deploy → CoreEngine

CoreEngine Application

The CoreEngine Application is the center of APIC. this app is the engine that drive the simulation.

OGI application

The APIC OGI is a UI (User Inferface) corss-platform application

The OGI application connect with the CoreEngine that can run on a different computer.

Advanced real-time topics

For Advance real-time Hardware, OS setup and software development, check out the following sections
